ELITE WOOD PLUS (Sumatra)
Made from certified White Teak, Elite Plus shutters are very high quality, light and strong. The side stiles are engineered to allow extra large panels to be made and to resist warping.
White teak is light and strong and has good looking grain when stained providing a highly professional finish for all styles of windows, from basic designs to unique shapes. You can choose multiple folding options, colours, stains and frames to suit your window style and they can be customised to miss protruding objects like handles, vents or skirting.
They have 25.4mm thick engineered side stiles with a simple or beaded design. Finished in a high quality 6 layer spray paint system with built-in UV inhibitor so perfect for most windows, doors and shapes.
Weight: 6.8-7.6kg per sqm
Colours available: 28
Stains available: 20
Custom Colours: Yes
Louvre sizes: 47mm, 64mm, 76mm, 89mm, 114mm
Control Rods: Centre, off set, hidden
Stiles: 40mm or 50mm wide, Butt, Rebate, DMould.
Sold panels: Yes
Bay posts: Yes
Fixed louvres: Yes
Guarantee: 3 Years
L Frames: Insert L Plain L, Beaded L, Bullnose L, Double insert, Double insert F
Z Frames: Bullnose, Deep Bullnose, Beaded, Crown, Deep Crown, Tiara
Deco: Camber, Ridge
Hang Strips: 27mm, 46mm, 60mm, 76mm
Tposts: 32mm, 46mm, 60mm, 76mm
Corner posts: 32mm, 46mm
Bay posts: 32mm, 46mm, + inserts
Side magnets: Yes
Frames: 3 or 4 sided
Rectangular frames only
Bay posts: Yes
25mm corded cellular blind
Min width 220mm
Min height 250mm
Max width 2500mm (5.5sqm)
Max height 3600mm (5.5sqm)
Blind colours: 15
Min panel width: 152mm
Min panel height: 250mm
Max panel width: 750mm (47mm), 890mm (64mm, 76mm), 1047mm (89mm, 114mm)
Max panel height: 3000mm
Max bi-fold panel width: 660mm
Max multi-fold panel width: 550mm
Max panel height without rail:1981mm
Max shutters hinged: 4
Unsupported shutters (Bottom gap larger than 2.5mm) : L, R, LR
Unsupported tracked shutters (No bottom track) : LL, RR, LLRR
Top and bottom rails sizes: 69.85mm-165.1mm
Middle rail sizes: 76.2mm
Width: Plus or Minus 1.6mm
Height: Plus or Minus 1.6mm
47mm louvre can be off by +/-19mm.
63mm louvre can be off by +/-25mm.
76mm louvre can be off by +/-31mm
89mm louvre can be off by +/-38mm.
114 mm louvre can be off by +/-51mm.
Tier on tier gap 2.5mm
HIDDEN TILT MAX LOUVRES
Maximum louvre quantity within one hidden tilt section.
Average 1400mm high shutter
64mm – 21
76mm – 16
89mm – 14
114mm – 10
Elite WOOD PLUS Tech Download
Not yet available
